Don’t guess when quality’s at stake!
SurfAce Diagnostics 1.3.3
Your companion for technical surfacing.
Curvature graph and analytic shaders
just one click away.

Why this exists
To help you achieve next level of quality
of any kind of technical surface with complex curvature.
Automotive, Product Design, Game Assets, … You name it.

What is inside
Zebra / Isoangle / Sections / Slice / Proximity / Draft / Radius / Curvature / CGraph / Angle Graph

……

* There is a bug in Blender 4.4 preventing to see material overrides visible in edit mode.
Surface Diagnostic addon will support 4.4.1 or 4.4.2 where this should be corrected.
Thanks for understanding! *
https://projects.blender.org/blender/blender/issues/136175
……
– Curvature shader – mean / gaussian / min / max –

– Radius shader –

– Draft –

– Proximity –

– Curvature Graph –

*note: For best experience, turn of GPU Subdivision
in Menu / Edit / Properties / Viewport / GPU Subdivison – see FAQs for more details

– Angle Graph-

– Zebra shader –

– Isoangle shader –

– Sections shader –

– Slice shader –

– Assets –
Blender file with all materials and geometry nodes included (All versions).

How it works
Key philosophy behind SurfAce Diagnostics is to utilize existing Blender tools as much as possible,
therefore Diagnostic Shaders and Curvature Graph are standard Blender nodetrees,
you can use them on their own in vanilla Blender, they play well with asset browser.
For best efficiency, there is custom scripted UI for single-click workflow,
which is shipped as complete addon with assets included.
Diagnostic Shaders are added to your objects using geometry node modifiers,
so your existing material set-ups remains untouched.
Curvature Graphs are added as new mesh objects, with custom geometry nodes modifier.
* Addon made with amazing Serpens Visual Scripting Addon Creator
